Aluminium Umbrellas
Type TS (storm safe)
Malzeme
Renkler
-
M00A White (00) -
M11A Yellow (11) -
M21A Beige (21) -
M22A Dark beige (22) -
M31A Red (31) -
M35A Bordeaux (35) -
M42A Dark green (42) -
M52A Dark blue (52) -
M81A Anthracite (81) -
M91A Black (91)
Product information
DESCRIPTION
The telescopic umbrella in the storm-resistant version which offers a special stability in wind-affected areas, such as in the mountains or the sea, which can withstand wind speeds of up to 80 km/h. Versions up to 100 km/h are possible. In this variant, all critical parts such as mast and struts are reinforced or replaced by stainless steel components. With matching rain gutter systems, several telescopic umbrellas can be flexibly formed into a combined roofing. Therefore, the TS model is one of the most popular umbrella types for gastronomy and industry.
COVER
The cover is made up of individual segments which are screwed to the frame by sterling steel hooks at the top and by rust-proof screws at the ends of the spokes. The cover is replaceable and is fade, light and water resistant. It is designed to withstand all weather conditions and can be ordered with valances. The PVC material is available in different colors.
The telescopic umbrella in the storm-resistant version which offers a special stability in wind-affected areas, such as in the mountains or the sea, which can withstand wind speeds of up to 80 km/h. Versions up to 100 km/h are possible. In this variant, all critical parts such as mast and struts are reinforced or replaced by stainless steel components. With matching rain gutter systems, several telescopic umbrellas can be flexibly formed into a combined roofing. Therefore, the TS model is one of the most popular umbrella types for gastronomy and industry.
COVER
The cover is made up of individual segments which are screwed to the frame by sterling steel hooks at the top and by rust-proof screws at the ends of the spokes. The cover is replaceable and is fade, light and water resistant. It is designed to withstand all weather conditions and can be ordered with valances. The PVC material is available in different colors.
ANCHOR
- Ground tube for smooth installation by means of foundation
- Foldable adapter for easy installation
- Ground tube for smooth installation by means of foundation
- Foldable adapter for easy installation
PRINTING
- Screen print
- Screen print
MAST
The spokes are made out of rectangular aluminium bars (50x20x3 mm – 60x30x3 mm). The center pole has a wounded aluminium profile ø 100x3 - 150x5 mm and aluminum telescope 60x60x3. The umbrella profile contains a U profile for the attachment of the spokes. The frame is powder coated (polyester powder ca. 80 μ.)
- White RAL 9010 (standard)
- Additional RAL tones are possible with an extra charge
The spokes are made out of rectangular aluminium bars (50x20x3 mm – 60x30x3 mm). The center pole has a wounded aluminium profile ø 100x3 - 150x5 mm and aluminum telescope 60x60x3. The umbrella profile contains a U profile for the attachment of the spokes. The frame is powder coated (polyester powder ca. 80 μ.)
- White RAL 9010 (standard)
- Additional RAL tones are possible with an extra charge
MECHANICS
The gearbox and the spindle are contained in the center pole and can be operated by handle or using a motor.
The gearbox and the spindle are contained in the center pole and can be operated by handle or using a motor.
BENEFITS
- Opening and closing by hand crank
- All materials are water and corrosion resistant
- All parts attached by screws can be easily replaced
- Mechanics include a telescopic pole which allows the umbrella to open or close over the table
- Maintenance-free gear box
- Possible with lights and heating
- Safely handles winds up to 80 km/h (with the proper bases)
- Opening and closing by hand crank
- All materials are water and corrosion resistant
- All parts attached by screws can be easily replaced
- Mechanics include a telescopic pole which allows the umbrella to open or close over the table
- Maintenance-free gear box
- Possible with lights and heating
- Safely handles winds up to 80 km/h (with the proper bases)
ACCESSORIES
- Various lighting options
- Protective sleeve with telescopic pole
- Event Platform and MDT Flex-Bar
- Wind walls with different heights
- Mobile ground flooring with wind walls that withstands any expected gust speeds
- Heaters
- Speakers
- Electric motor for opening the umbrella (can also be used for the wind walls)
- Rain gutter to connect adjoining umbrellas
- Cloth side walls with doors or windows
- Cabling is housed within the central mast
- Various lighting options
- Protective sleeve with telescopic pole
- Event Platform and MDT Flex-Bar
- Wind walls with different heights
- Mobile ground flooring with wind walls that withstands any expected gust speeds
- Heaters
- Speakers
- Electric motor for opening the umbrella (can also be used for the wind walls)
- Rain gutter to connect adjoining umbrellas
- Cloth side walls with doors or windows
- Cabling is housed within the central mast
