Umbrella bar
Type GC
Malzeme
Renkler
-
M00FR White (00) -
M11FR Yellow (11) -
M21FR Beige (21) -
M31FR Red (31) -
M35FR Bordeaux (35) -
M41FR Green (41) -
M42FR Dark green (42) -
M52FR Dark blue (52) -
M61FR Silver (61) -
M81FR Anthracite (81) -
M91FR Black (91)
-
M00A White (00) -
M11A Yellow (11) -
M21A Beige (21) -
M22A Dark beige (22) -
M31A Red (31) -
M35A Bordeaux (35) -
M42A Dark green (42) -
M52A Dark blue (52) -
M81A Anthracite (81) -
M91A Black (91)
-
M00PVC White (00) -
M11PVC Yellow (11) -
M21PVC Beige (21) -
M31PVC Red (31) -
M35PVC Bordeaux (35) -
M41PVC Green (41) -
M42PVC Dark green (42) -
M52PVC Dark blue (52) -
M61PVC Silver (61) -
M91PVC Black (91)
Product information
DESCRIPTION
The gastronomy concept combines mobile foodservice and maximum functionality as a result of countless accessories. It offers the ability to create a mobile hospitality service or expand an existing dining area. This makes it easy to generate more sales and increase hospitality at any location.
COVER
The cover is made up of individual segments which are screwed to the frame by Sterling Steel hooks at the top and by rust-proof screws at the ends of the spokes. The cover is replaceable and is fade, light and water resistant. It is designed to withstand all weather conditions and can be ordered with valances.
ANCHOR
Galvansteel construction including floor panel
PRINTING
- Digital print
- Screen print
- Dispersion dye print
MAST
The spokes are made out of square aluminium bars (40x20x2 mm – 50x20x3 mm). The centre pole has a wounded aluminium profile. The umbrella profile contains a U profile for the attachment of the spokes. The frame is powder coated (polyester powder ca. 80 μ).
- White RAL 9010 (standard)
- Black RAL 9005
- Silver RAL 9006
BASIC DESIGN
Made up of multiple segments 2x1m large. All segments are of none rusting galvanized steel.The adaptor is hinged to allow easy lower or raising of umbrella.
MECHANICS
The gearbox and the spindle are contained in the centre pole and can be operated by handle or using a motor.
BENEFITS
- Opening and closing by hand, or alternatively using an electric motor
- All materials are resistant to the effects of water corrosion
- All material are screwed together and can be replaced easily
- Telescopic pole allows the umbrella to open and close above table height
- Maintenance-free gear box
- Lighting available
- Possible with foldable light and heating
ACCESSORIES
- Various lighting possibilities
- Transport case
- Protective sleeve with a telescopic pole
- Event Platform and MDT Flex-Bar
- wind sheltering side walls available in different heights
- Heaters
- Speakers
- Electric motor to open and close the umbrella in combination with a wind watcher
- Multiple umbrellas can be connected with a rain junction (Available only with valances)
- Cabling is housed within the central mast
