Type S16

MDT-Tex introduces a premium range of technical parasols, specifically tuned to customers that require an aesthetic touch to our wind-stable umbrellas. The new Home collection offers several advantages to our classic line including strong and lightweight extruded hubs, fabric protecting corner caps, a simpler and lighter tensioning system and sleek frame-base covers for mobile units. The new range of umbrellas set a new standard in terms of aesthetics and functionality without compromising any of the strength and quality standards that exist in our industrial ranges.

The textile cover is attached to the spoke ends by aluminium end caps and stainless steel bolts. The cover is replaceable and is fade, light and water resistant. It is designed to withstand all weather conditions.

• Frame base to be loaded with concrete blocks
• Ground tube (type 060)

• Digital print
• Screen print
• Dispersion dye print

Umbrella spokes are made of rectangular aluminium sections of 30 x 20 x 2 mm. The mast is made of a round aluminium section of 60 mm. The aluminium telescope has section dimensions of 30 x 30 x 3 mm. Strut connecting hubs are made of extruded aluminium high strength profile. All parts are screwed together and the frame, the end caps, acorn, hub and the handle (anthracite) is powder coated (Polyester powder ca. 80 μ).

• White RAL 9010 (standard)
• Anthracite DB 703 MT GL PE

The tension mechanism of the umbrella is operated by an aluminium handle with zinc coated spring steel strap that controls an internal telescope system.

• Open and closes with a single hub-mounted aluminium handle
• All materials are resistant to the effects of water corrosion
• Telescopic pole allows the umbrella to open and close above table height
• Full aluminium umbrella
• Electric cables are hidden from sight within four chamber column inside the centre mast
• All struts in the open state replaceable
• All umbrella parts recyclable
• Designed to withstand wind speeds up to 60 km/h (with the proper ground anchorage)

• LED lighting
• Protective sleeve with a telescopic pole
• Rain gutter to connect adjoining umbrellas (only square umbrellas)
• Cover for frame base
